90-Degree and 180-Degree

13918167735

Model Number	Interface	Description	F Low (MHz)	F High (MHz)	Isolation (dB), Typ.	Insertion Loss (dB) Above Theoretical, Typ.	Phase Unbalance (deg), Typ.	Amplitude Unbalance (dB), Typ.	Input Power, Max.	Technology	Case Style
ADPQ-2-250+	SMT	90° Hybrid	150	250	24	0.2	4	1.4	1	Core & Wire	CD637
ADQ-22+	SMT	90° Hybrid	95	200	28	0.3	6	1.6	0.5	Core & Wire	CJ725
ADQ-32+	SMT	90° Hybrid	160	327	22	0.3	5	1.6	0.5	Core & Wire	CJ725
ADQ-32W+	SMT	90° Hybrid	104	340	20	0.6	8	1.8	0.5	Core & Wire	CJ725
ADQ-90+	SMT	90° Hybrid	55	90	26	0.2	4	1.2	0.5	Core & Wire	CJ725
ADQ-180+	SMT	90° Hybrid	120	180	35	0.2	6	1.5	0.5	Core & Wire	CJ725
AMT-2+	SMT	0°/180° Hybrid	50	200	35	0.8	2	0.3	0.5	Core & Wire	CD636
AMT-32+	SMT	0°/180° Hybrid	1	300	35	0.9	2	0.3	0.5	Core & Wire	CD636
EPQ-113+	SMT	90° Hybrid	5000	11000	19	0.6	8.8	1.5	1.59	MMIC	DG1847
EPQ-113-D+	Die	90° Hybrid	5000	11000	19	0.6	1.4	1.5	1.6	MMIC
EPQ-133+	SMT	90° Hybrid	6000	14000	20	0.6	8.8	1.6	1.58	MMIC	DG1847
EPQ-133-D+	Die	90° Hybrid	6000	14000	20	0.6	8.8	1.6	1.6	MMIC
JSPQ-65W+	SMT	90° Hybrid	5	65	33	0.7	5	0.7	1	Core & Wire	BK276
JSPQ-80+	SMT	90° Hybrid	10	80	44	0.45	6	0.6	1	Core & Wire	BK276
JSPQ-350+	SMT	90° Hybrid	150	350	20	0.5	5	1.5	1	Core & Wire	BK276
JSPQW-100+	SMT	90° Hybrid	40	100	24	0.2	3	1.2	1	Core & Wire	BK276
JSPQW-100A+	SMT	90° Hybrid	30	100	41	0.5	4	0.6	1	Core & Wire	BK276
JYPQ-30+	SMT	90° Hybrid	16	30	28	0.2	3	1.5	1	Core & Wire	BJ293
JYPQ-160+	SMT	90° Hybrid	105	160	24	0.25	3	1.5	1	Core & Wire	BJ293
PQW-2-90+	Plug-In	90° Hybrid	30	90	27	0.3	3	1	1	Core & Wire	A01
