Voltage Controlled Oscillators (VCOs)

型号
Voltage Controlled Oscillators (VCOs)

规格
35 to 6840 MHz

品牌
Mini-Circuits

13918167735

产品参数
说明书下载

Model Number	Case Style	Freq. Low (MHz)	Freq. Hi (MHz)	Power Output (dBm) Typ.	Tune Voltage (V) Min.	Tune Voltage (V) Max.	Phase Noise (dBc/Hz) @ 1 kHz Offset, Typ.	Phase Noise (dBc/Hz) @ 1 0kHz Offset, Typ.	Phase Noise (dBc/Hz) @ 100 kHz Offset, Typ.	Phase Noise (dBc/Hz) @ 1 MHz Offset, Typ.	Pulling (MHz) pk - pk @ 12 dBr, Typ.	Pushing (MHz/V), Typ.	Tuning Sensitivity (MHz/V) Typ.	Harmonics (dBc), Typ.	Harmonics (dBc), Max.	3 dB Control BW (MHz), Typ.	DC Voltage (V)	DC Current (mA)
JTOS-75+	BK377	37.5	75	8.0	1.0	16	-90	-111	-131	-152	0.05	0.11	2.7-3.4	-32	-20	0.10	12	20
JTOS-150+	BK377	75	150	9.5	1.0	16	-82	-106	-127	-147	0.80	0.30	5.8-6.7	-23	-17	0.11	12	20
JTOS-850VW+	BK377	400	850	6.0	0.50	18	-74	-96	-116	-136	6.0	1.5	15-80	-20	-	0.18	5.0	20
JTOS-1550+	BK377	1150	1550	9.0	0.50	18	-72	-100	-122	-142	14	1.2	20-45	-18	-10	100	12	32
JTOS-1650+	BK377	1200	1650	7.0	1.0	13	-70	-95	-115	-135	15	1.5	50-90	-20	-14	1.0	12	30
ROS-200-719R+	CK605	144	200	9	0.5	16	-95	-122	-142	-161	0.10	0.10	5.0	-20	-10	50	12	33
ROS-244R+	CK605	170	244	10	2.0	16	-94	-120	-140	-160	0.20	0.10	5-10	-18	-	50	12	34
ROS-310-519+	CK605	240	305	6.0	0.50	17	-89	-112	-133	-153	0.50	0.70	5.0-7.0	-24	-14	40	5.0	30
ROS-386-119+	CK605	295	386	9.5	4	16	-90	-117	-138	-158	0.20	0.40	10	-23	-12	18	12.0	31
ROS-435-119+	CK605	425	435	2.5	0.5	10	-93	-118	-139	-159	0.20	0.10	5-6	-22	-15	50	5.0	30
ROS-470-319+	CK605	460	470	5.0	1.0	10	-94	-118	-138	-157	0.10	0.10	6.0	-21	-15	100	5.0	22
ROS-480+	CK605	386	480	9.5	3.0	16	-88	-115	-137	-158	0.25	0.45	8-12	-20	-13	30	12	31
ROS-890CR+	CK1113	875	890	6.2	0.50	11	-97	-125	-145	-165	0.3	0.2	5	-19	-12	60	8.0	35
ROS-1121V+	CK605	1060	1121	2.5	1.0	11	-88	-111	-131	-149	0.70	0.70	8-13	-11	-	10	5.0	30
ROS-1150-519+	CK605	750	1150	6.5	0.50	13.5	-75	-99	-121	-141	5.0	1.0	38-45	-20	-12	70	5.0	35
ROS-1150C-119R+	CK1113	1146	1154	3	0.50	11	-96	-121	-141	-161	0.2	0.1	3	-22	-12	45	5.0	35
ROS-1410+	CK605	850	1410	7.0	0.50	11	-73	-99	-119	-138	15	1.0	50-80	-8	-	1.0	12	25
ROS-1445-219+	CK605	1145	1445	8	1	20	-78	-106	-129	-149	5	0.5	35-42	-12	-	60	10.0	30
ROS-1600W+	CK605	800	1600	9.0	0.50	24	-72	-99	-122	-143	10	0.30	35-58	-22	-15	90	11.5	35
ROS-1645W-119+	CK605	1200	1645	8.0	0.50	16	-79	-106	-127	-147	4.0	0.20	26-43	-19	-10	80	10	30
ROS-1700W+	CK605	770	1700	9.0	1.0	24	-72	-99	-120	-141	7.0	0.70	26-65	-25	-9	50	12	35
ROS-1707-119+	CK605	1033	1707	8.0	0.50	24	-74	-100	-121	-142	10.5	2.0	32-59	-15	-	100	10	35
ROS-1790-519R+	CK605	1640	1790	6.5	0.5	12	-82	-107	-127	-147	4	0.7	19	-28	-20	50	5.0	36
ROS-1801C-119+	CK1113	1800	1800	6.0	0.5	9.5	-101	-126	-147	-166	0.2	0.1	1.5	-16	-	50	8.0	37
ROS-1900+	CK605	1450	1900	7.0	0.50	20	-80	-106	-126	-146	7.0	0.70	22-34	-15	-7	100	10	25
ROS-2100-119+	CK605	1350	2100	8.5	0.50	18.5	-76	-102	-123	-143	8.5	0.50	46-72	-18	-	60	8.0	35
ROS-2150VWR+	CK605	970	2150	4.0	0.50	25	-71	-99	-122	-142	5.0	1.0	25-80	-22	-	15	5	27
ROS-2160W+	CK605	1160	2160	5.0	0.50	20	-70	-97	-117	-137	10	1.5	30-80	-11	-	12	10	30
ROS-2170-1319R+	CK605	1730	2170	7.5	0.5	12	-76	-103	-124	-144	4	0.3	52-60	-17	-	30	12	34
ROS-2350-519+	CK605	1960	2350	7.0	0.50	15	-80	-106	-126	-146	5.0	0.30	34-37	-18	-10	115	5.0	40
ROS-2432-119+	CK605	1662	2432	5.5	1.0	28	-73	-100	-123	-143	6.5	1.0	23-49	-18	-	230	10	30
ROS-2450C+	CK1113	2120	2450	7.0	0	15	-80	-107	-128	-148	3.0	0.3	28-35	-23	-12	150	6.0	34
ROS-2490+	CK605	2280	2490	8.0	0.50	10	-80	-104	-124	-144	1.0	1.0	30-37	-20	-11	140	5.0	38
ROS-2490C+	CK1113	2020	2490	7.20	0.25	16	-79	-107	-128	-149	2.5	0.4	30-40	-32	-15	45	8.0	40
ROS-2500+	CK605	1600	2500	7.5	0.50	14	-62	-89	-111	-131	18	2.0	70-118	-16	-	20	12	28
ROS-2600-1119+	CK605	1650	2600	6.0	0.3	28	-75	-102	-122	-142	2.5	1.0	25-60	-18	-	30	10	53
ROS-2600C+	CK1113	2130	2600	6.7	0.5	16	-78	-105	-126	-147	1.5	0.5	35-49	-26	-13	75	8.0	40
ROS-2700-1819+	CK605	1300	2700	3.3	0.15	25	-69	-93	-114	-136	6.0	1.6	42-49	-23	-	25	5.0	35
>ROS-2750+	CK1113	2350	2750	5.7	0.50	14.5	-78	-105	-127	-146	2.0	0.30	32-42	-23	-12	120	6.0	35
ROS-2760C-119R+	CK1113	2600	2760	4.0	0.50	18	-85	-113	-133	-153	0.80	0.30	12-16	-16	-9.0	60	8.0	37
ROS-2960C-119+	CK1113	2500	2920	7.0	0.50	16	-79	-107	-128	-147	2.0	0.20	34-42	-25	-15	150	8.0	38
ROS-3000-819+	CK605	2000	3000	5.5	0.50	14	-71	-96	-117	-138	13.5	1.5	84-125	-22	-10	140	12	35
ROS-3050-819+	CK605	2150	3050	7.0	0.50	11.5	-67	-94	-115	-135	2.0	1.7	98-122	-20	-10	200	5.0	49
ROS-3050C+	CK1113	2635	3050	6.5	0.50	16	-77	-104	-125	-145	4.5	0.20	35-47	-22	-12	100	8.0	40
ROS-3360R+	CK605	2120	3360	9.0	0.50	18	-64	-93	-116	-136	9.0	1.5	77-123	-20	-12	170	12	45
ROS-3570-319+	CK829	3230	3570	6.0	0.50	16	-75	-99	-120	-140	6.5	0.70	27-33	-22	-13	100	5.0	40
ROS-3600-419R+	CK605	3300	3605	8.5	0.50	8	-71	-97	-118	-138	3.5	2.5	57-78	-20	-15	130	5.0	46
ROS-3800-119R+	CK605	1900	3700	6	0.5	20	-61	-88	-110	-130	2	6	60-150	-22	-10	10	6.0	55
ROS-3900-419+	CK605 LxWxH 0.50x0.50x0.18	3650	3900	4.5	0.50	12	-72	-96	-118	-138	2.0	4.0	34-40	-20	-12	100	5.0	40
ROS-4000-419R+	CK605	3850	4000	5.0	0.50	10	-74	-99	-120	-140	5.0	1.5	24-36	-26	-16	13	5.0	42
ROS-4415-119R+	CK605	4214	4415	5.0	1.0	10	-69	-95	-118	-138	2.5	4.5	52-57	-27	-15	150	5.0	45
ROS-4861C-119+	CK1113	4859	4861	7.5	0.5	8	-80	-108	-132	-153	1.5	0.3	5-6	-23	-16	200	8.0	37
ROS-6840C-119+	CK1113	6740	6840	1	0.50	4.5	-69	-95	-119	-139	1	6	85-100	-22	-12	125	5.0	38
