Model Number	F Low (MHz)	F High (MHz)	Gain (dB) Typ.	NF (dB) Typ.	P1dB(dBm) Typ.	OIP3 (dBm) Typ.	Input VSWR (:1) Typ.	Output VSWR (:1) Typ.	Voltage (V)	Current (mA)
ADCA3270	45	1218	25	3	-	-	1.43	1.2	24	350/480
ADCA3280	45	1794	22.7	3.3	-	-	1.32	1.25	18/24	450/570
ADCA3950	45	1218	25	3	-	-	1.28	1.2	24	470/490
ADCA3952	45	1218	25	3	-	-	1.28	1.2	24	250/490
ADCA3990	45	1218	24.5	3	-	-	1.4	1.17	24/34	400/550
ADCA3992	45	1218	26.7	3	-	-	1.19	1.13	24/34	300/550
ADCA5190	5	1800	19.1	3	-	-	1.37	1.28	5/8	200/450
ADCA5191	5	1800	25.8	3.4	-	-	1.2	1.28	5/8	250/530
ADCA5192	5	1794	17	1.7	-	-	1.25	1.37	5	250
AMP-15	5	1000	13	2.8	8	22	2	2	15	29
AMP-75+	5	500	19	2.4	12	28	2	2	15	31
AMP-77+	5	500	15	3.3	16	32	2	2	15	56
AVA-5R183-D+	500	18000	13.3	2.8	18.6	23.3	1.33	1.119	5	85
AVA-5R183+	500	18000	14.4	3.4	16.8	27.9	1.38	1.28	5	85
AVA-24A+	5000	20000	11.8	5.7	18.4	25	1.38	1.7	5	120
AVA-24A-D+	5000	22000	13	5.8	19.2	25	1.3	1.9	5	126
AVA-054-D+	DC	50000	16.1	4	19.3	26.9	1.32	1.37	5	160
AVA-183A+	5000	18000	14	5	19	26	1.9	1.9	5	131
AVA-183A-D+	5000	20000	14.5	4.3	18.2	25	1.6	1.7	5	131
AVA-183P+	500	18000	8.1	4.8	11.7	21.5	1.67	1.92	5	46
AVA-183P-D+	500	18000	8.1	4.8	11.7	21.5	1.67	1.92	5	46
AVA-183MP+	50	18000	16.5	1.8	23.8	31.1	1.53	1.22	8	160
AVA-183MP-D+	DC	18000	14.5	2.8	23.2	29.5	1.49	1.25	8	160
AVA-223MP+	0.1	22000	13.9	3	26	38.2	1.28	1.28	10	300
AVA-223MP-D+	0.1	22000	13.7	3.1	25.9	37.9	1.32	1.32	10	300
AVA-0233LN+	2000	30000	17	2.2	13.5	25.7	1.33	1.22	5	65
AVA-0233LN-D+	2000	30000	17	2.2	13.5	25.7	1.33	1.22	5	65.2
AVA-2183+	2000	20000	16.4	5.2	19.3	24.7	1.45	1.22	4	210
AVA-2183-D+	2000	18000	17.2	5.5	19.6	27.4	1.49	1.25	4	210
AVA-6123MP+	5600	11700	22.4	5.9	21.6	28.2	1.38	1.32	5	140
AVA-6183MPS+	6000	18000	20.9	5.6	26	32.6	1.67	1.43	6	663
AVA-6183MPS-D+	6000	18000	20.9	5.8	26.9	33.3	1.49	1.25	6	663
AVA-17303+	17000	31500	20.5	4.1	22.9	33	1.67	1.67	6	160
AVA-17303-D+	17000	31500	19.2	3.6	23.8	36	2.10	1.58	6	160
AVA-20453BL-D+	20000	45000	23.5	9.7	23	30	1.3	1.3	5	450
AVA-20453MP-D+	20000	45000	20.8	9.2	20.5	27.7	1.67	1.28	4.5	300
AVA-26453LN-D+	26000	45000	22.2	2.9	11.1	19.2	1.68	1.49	3	80
CMA-62+	10	6000	15.4	5.1	19.2	33	1.5	1.8	5	82
CMA-63+	10	6000	20.3	3.9	18.4	32	1.1	1.4	5	69
CMA-81+	DC	6000	10	7.4	19.6	34	1.3	1.6	5	103
CMA-82+	DC	7000	14.1	6.7	20.6	36.4	1.4	1.9	5	106
CMA-83LN+	500	8000	21.5	1.3	20.3	30.1	1.32	1.31	5.0/6.0	50/62
CMA-84+	DC	7000	20.2	5.5	21	34.5	1.4	3	5	108
CMA-103+	50	4000	11.0	0.8	23.1	44.8	1.38	1.36	3.0/5.0	60/97
CMA-162LN+	700	1600	23.2	0.49	19.9	30.3	1.4	1.2	4	55
CMA-183L+	DC	18000	14.2	5.5	5.4	17.5	-	-	5	20
CMA-252LN+	1500	2500	16.8	1	17.8	30	1.5	1.3	4	57
CMA-545+	50	6000	14.2	0.8	20	35	2.3	1.5	3	80
CMA-545G1+	400	2200	31.8	0.9	23.3	36.5	1.9	1.4	5	158
CMA-5043+	50	4000	18.4	0.75	19.8	33.5	1.7	1.5	5	58
DVGA1-242A+	450	2400	29.3	2.4	22.9	35.9	2.43	1.66	5	155
DVGA1-242APP+	450	2400	29.5	2.6	22.8	35.5	2.54	1.39	5	158
DVGA2-33A+	50	3000	18.1	5.3	18	31.3	1.6	1.43	5	91
DVGA2-33APP+	50	3000	19.3	5.3	16.4	31.5	1.53	1.39	3 & 5	91
DVGA3-122+	900	1200	20	0.5	15.6	28	1.92	2.6	5	52.2
EHA-24L-D+	DC	20000	13.4	5.1	6.8	16.6	1.433	1.377	5	19.1
EHA-163L+	DC	16000	15.3	5.2	6.5	15.6	1.67	1.57	5	20.9
EHC-24L+	DC	20000	15.1	5.2	7	19.2	1.28	1.43	5	19.1
ERA-1+	DC	8000	10.9	4.3	12	26	1.5	1.5	3.4	40
ERA-1SM+	DC	8000	10.9	4.3	12	26	1.5	1.5	3.4	40
ERA-2+	DC	6000	14.4	4	13	26	1.3	1.2	3.4	40
ERA-2SM+	DC	6000	14.4	4	13	26	1.3	1.2	3.4	40
ERA-3+	DC	3000	18.7	3.5	12.5	25	1.5	1.4	3.2	35
ERA-3SM+	DC	3000	18.7	3.5	12.5	25	1.5	1.4	3.2	35
ERA-4+	DC	4000	13.4	4.2	17.3	34	1.2	1.3	4.5	65
ERA-4SM+	DC	4000	13.4	4.2	17.3	34	1.2	1.3	4.5	65
ERA-5+	DC	4000	18.5	4.3	18.4	32.5	1.3	1.2	4.9	65
ERA-5SM+	DC	4000	17.6	4.3	18.4	32.5	1.3	1.2	4.9	65
ERA-6+	DC	4000	12.2	4.5	17.9	36	1.3	1.6	5	70
ERA-6SM+	DC	4000	12.2	4.5	17.9	36	1.3	1.6	5	70
ERA-8SM+	DC	2000	19	3.1	12.5	25	1.4	1.8	3.7	36
ERA-9SM+	DC	8000	8.3	5.3	14.1	31.3	1.2	1.2	4	50
ERA-21SM+	DC	8000	12.2	4.7	12.6	26	1.1	1.3	3.5	40
ERA-33SM+	DC	3000	17.4	3.9	13.5	28.5	1.6	1.25	4.3	40
ERA-50SM+	DC	2000	19.4	3.5	17.2	32.5	1.3	1.2	4.4	60
ERA-51SM+	DC	4000	16.1	4.1	18.1	33	1.1	1.2	4.5	65
ERA-51SM-D+	DC	4000	16.1	4.1	18.1	33	1.1	1.2	4.5	65
GALI-1+	DC	8000	11.8	4.5	10.5	27	1.3	1.4	3.4	40
GALI-2+	DC	8000	14.8	4.6	11	27	1.6	1.6	3.5	40
GALI-3+	DC	3000	19.1	3.5	10.5	25	1.5	1.2	3.3	35
GALI-4+	DC	4000	13.5	4	16	34	1.2	1.4	4.6	65
GALI-4F+	DC	4000	13.4	4	13.8	32	1.2	1.5	4.4	50
GALI-5+	DC	4000	17.5	3.5	16	35	1.2	1.4	4.4	65
GALI-5F+	DC	4000	17.4	3.5	14.2	31.5	1.2	1.4	4.3	50
GALI-6+	DC	4000	11.3	4.5	18.2	35.5	1.5	1.8	5	70
GALI-6F+	DC	4000	11.6	4.5	15.8	35.5	1.5	1.9	4.8	50
GALI-19+	DC	7000	11.6	6.5	9	23.7	1.6	1.5	3.6	40
GALI-21+	DC	8000	13.1	4	10.5	27	1.1	1.3	3.5	40
GALI-24+	DC	6000	16.6	4.3	19.3	35.3	1.4	2	5.8	80
GALI-29+	DC	7000	19.7	6	10	24.7	1.5	1.5	3.6	40
GALI-33+	DC	4000	17.5	3.9	11.4	28	1.6	1.2	4.3	40
GALI-39+	DC	7000	19.7	2.4	9	22.9	1.6	1.5	3.5	35
GALI-39-D+	DC	7000	19.7	2.4	10.5	22.9	1.79	2.3	3.5	35
GALI-49+	DC	5000	13.6	4.4	16.4	33.3	1.2	1.2	4.5	65
GALI-51+	DC	4000	16.1	3.5	16.5	35	1.3	1.5	4.5	65
GALI-51F+	DC	4000	15.9	3.5	14.4	32	1.2	1.5	4.4	50
GALI-52+	DC	2000	17.8	2.7	15.5	32	1.35	1.4	4.4	50
GALI-55+	DC	4000	18.5	3.3	15.5	28.5	1.25	1.3	4.3	50
GALI-59+	DC	5000	18.3	4.3	17.6	33.3	1.6	1.5	4.8	65
GALI-74+	DC	1000	21.8	2.7	18.3	38	1.2	1.6	4.8	80
GALI-84+	DC	6000	16.7	4.4	21	37.4	1.4	2.1	5.8	100
GALI-S66+	DC	3000	18.2	2.4	3.3	19.1	1.1	1.2	3.5	16
GALI-S66-D+	DC	3000	18.2	2.4	3.3	19.1	1.1	1.2	3.5	16
GVA-60+	10	5000	19.8	4	19.5	35.6	1.4	1.9	5	92
GVA-60-D+	10	6000	19.3	3.9	18.2	29	1.45	2.2	5	93
GVA-62+	10	6000	15.4	5.1	19.2	33.6	1.5	1.3	5	82
GVA-62-D+	10	6000	15.7	5	19.4	32.8	1.4	1.4	5	82
GVA-63+	10	6000	20	3.7	18.6	32.2	1.1	1.35	5	69
GVA-63-D+	10	6000	20.5	3.7	18.2	31.9	1.18	1.5	5	69
GVA-81+	DC	6000	10	7.4	19.7	36.6	1.3	1.3	5	103
GVA-81-D+	DC	6000	10	7.4	19.7	36.6	1.3	1.3	5	103
GVA-82+	DC	7000	13.8	6.6	20.6	36	1.3	1.6	5	106
GVA-83+	DC	7000	17.1	6.2	18.6	31.5	1.3	1.8	5	72
GVA-84+	DC	7000	16	5.5	20.6	35.8	1.3	2.6	5	108
GVA-84-D+	DC	7000	16	5.5	21	35.8	1.28	2.58	5	108
GVA-91+	869	2170	20.4	6.4	28.8	40	1.8	1.3	5	147
GVA-92+	869	2170	21.2	6	24.1	42	1.8	2	5	99
GVA-93+	10	9000	16.9	4	16.2	30	1.2	1.2	5	52
GVA-123+	10	12000	16.9	4	16.2	30	1.2	1.2	5	52
GVA-123-D+	10	12000	16.7	3.9	15.9	29.1	1.2	1.2	5	48
HPA-25W-63+	700	6000	53	13	37	45	1.8	2.0	110/220 AC	-
HPA-25W-272+	20	2700	50	10	38	50	1.3	2.5	110/220 AC	-
HPA-50W-63+	700	6000	56	12	43	50	2.5	3	110/220 AC	-
HPA-100W-63+	2500	6000	58	15	43	50	2.5	2.5	110/220 AC	-
HPA-272+	700	2700	48	8.2	49	55	1.3	1.3	110/220 AC	-
HXG-122+	500	1200	15.3	2.2	23	46	1.6	1.8	5	144
HXG-242+	700	2400	15	2.3	22.8	46.5	1.9	1.4	5	144
LEE-9+	DC	8000	8.4	5.3	13.9	29.7	1.2	1.2	4	50
LEE-19+	DC	8000	12	6.5	10.2	24.5	1.5	1.4	3.6	40
LEE-29+	DC	8000	15.4	5.5	10.9	25.5	1.4	1.3	3.6	40
LEE-39+	DC	8000	20.8	2.4	10.4	23.4	1.3	1.3	3.5	35
LEE-49+	DC	5000	14	5.5	16.4	33	1.6	1.4	4.9	65
LEE-59+	DC	5000	19.7	4.5	17.3	33	1.5	1.5	4.8	65
LEE2-6+	DC	7000	18.9	2.3	2.8	17.6	1.33	1.54	3.6	16
LHA-1+	50	6000	14.1	2.1	22.7	40	1.7	1.4	5	146
LHA-1H+	50	6000	12.2	2.5	22.7	40.9	1.87	1.27	5	145
LHA-13HLN+	1	1000	22.7	1.2	28	43.3	1.28	1.32	8	239
LHA-13LN+	1	1000	22.4	1.1	23.3	38.3	1.28	1.28	5/3	143/73
LHA-23HLN+	30	2000	21.5	1.3	28.3	44.7	1.9	1.5	8	244
LHA-23LN+	30	2000	21.2	1.2	23.8	36.9	1.9	1.25	5/3	146/75
LHA-83W+	50	8000	16.8	3.1	23.3	35.1	1.14	1.21	5/9	40/105
LHY-1H+	50	6000	14	2.1	22.5	41	1.79	1.26	5/4.5/4	144/116/80
LHY-84+	DC	7000	20	5.4	21	33.1	1.43	2.1	5	111
LVA-123+	10	12000	17.3	3.9	15.6	28.2	1.2	1.35	5	52
LVA-273PN+	10	26500	17.7	3.7	18.3	28.1	1.22	1.47	5	85
LVA-273PN-D+	10	26500	18	3.6	18.5	27.7	1.22	1.23	5	85
LVA-6183PN+	6000	18000	19.9	4.1	19.6	28.7	1.22	1.22	6	123
LVA-6183PN-D+	6000	18000	19.5	4.1	19.3	28.9	1.23	1.22	6	123
LZY-22+	0.1	200	43	8.9	42	52	1.4	4	24	6000
LZY-22X+	0.1	200	43	8.9	42	52	1.4	4	24	6000
MAR-1SM+	DC	1000	16.5	3.3	2.5	14	1.3	1.2	5	17
MAR-2SM+	DC	2000	12	3.7	7	22	1.3	1.3	5	25
MAR-3+	DC	2000	12	6	10	23	1.5	1.7	5	35
MAR-3SM+	DC	2000	12	3.7	10	28	1.3	1.3	5	35
MAR-4+	DC	1000	8	7	12.5	25.5	1.5	1.9	5.25	50
MAR-4SM+	DC	1000	8	6	12.5	25.5	1.6	2	5.3	50
MAR-6+	DC	2000	20	3	3	14.5	1.7	1.7	3.5	16
MAR-6SM+	DC	2000	20.2	2.3	3.7	18.1	1.2	1.2	3.5	16
MAR-7SM+	DC	2000	12.5	5	3.5	19	1.3	1.3	4	22
MAR-8A+	DC	1000	25	3.1	12.5	25	1.4	1.8	3.7	36
MAR-8A-D+	DC	1000	31.5	3.1	12.5	25	1.4	1.79	3.7	36
MAR-8ASM+	DC	1000	25	3.1	12.5	25	1.4	1.8	3.7	36
MAV-11BSM+	50	1000	11.3	4.4	18	34	1.2	1.2	5.5	60
MERA-533+	DC	4000	18.8	3.5	17.5	33	1.4	1.5	4.9	65
MERA-556+	DC	2200	19	3.5	17.6	35.5	1.2	1.4	4.9	65
MERA-7433+	DC	1000	19	2.7	18.3	35	1.25	1.8	4.8	80
MERA-7456+	DC	1000	18.6	2.7	18.2	35	1.3	2	4.8	80
MGVA-62+	40	3000	15.7	4.8	19.6	37.9	1.65	1.24	5	82
MGVA-63+	40	3000	21.4	3.6	19.4	34.3	1.35	1.32	5	69
MGVA-82+	DC	5200	14.1	7	20.2	36	1.3	1.7	5	100
MNA-2A+	500	2500	15	5.3	17.9	29	1.3	1.4	2.8/5.0	79/84
MNA-2A-D+	500	4500	14.7	5.4	17.5	29	1.3	1.5	2.8/5.0	79/84
MNA-2W+	500	4500	14.7	5.4	17.5	29	1.3	1.5	2.8/5.0	79/84
MNA-3A+	500	2500	16.5	4	9.5	21	1.24	1.22	2.8/5.0	32.6/34.3
MNA-3A-D+	500	2500	16.8	3.9	10.3	22	1.3	1.2	2.8/5.0	32.6/34.3
MNA-4A+	500	2500	17.8	4.4	18.6	30.8	1.5	1.1	2.8/5.0	70.6/75
MNA-4A-D+	500	4500	17	4.5	16.8	27.9	1.5	1.5	2.8/5.0	70.6/75
MNA-4W+	500	4500	17	4.5	16.8	27.9	1.5	1.5	2.8/5.0	70.6/75
MNA-5A+	500	2500	22.8	3	10.4	21.3	1.2	1.7	5	34
MNA-5A-D+	500	4500	19.2	3.2	8.7	19.1	1.3	1.6	2.8/5.0	32/34
MNA-5W+	500	4500	19.2	3.2	8.7	19.1	1.3	1.6	5	34
MNA-6A+	500	2500	25	2.6	20.2	32.4	1.5	1.1	2.8/5.0	92/99
MNA-6A-D+	500	5500	23.2	2.7	19.2	30	1.4	1.2	2.8/5.0	92/99
MNA-6W+	500	5500	23.2	2.7	19.2	30	1.4	1.2	2.8/5.0	92/99
MNA-7A+	1500	6000	17.7	5.7	17.1	28.5	1.8	1.2	2.8/5.0	77/82
MNA-7A-D+	1500	6000	17.7	5.7	17.1	28.5	1.8	1.2	2.8/5.0	77/82
MPGA-105+	40	3000	14.4	1.9	21	37.8	1.2	1.4	5	63
MPGA-122-75+	40	1250	15.3	3.2	30.6	48.8	1.21	1.36	9	391
MPGA-152+	30	1500	14.6	3.2	29.6	43.6	1.21	1.23	9	407
PGA-32-75+	5	300	15.6	2.9	23.7/18.7	43.3/39.1	1.16	1.08	9.0/5.0	110/55
PGA-32-75-D+	5	300	15.6	2.9	23.7/18.0	43.3/31.6	1.16	1.08	9.0/5.0	110/50.7
PGA-102+	50	6000	15.9	2.3	17.4	32.7	1.27	1.27	3.3	83
PGA-103+	50	4000	11	0.9	22.5	44.6	1.6	1.2	3.0/5.0	60/97
PGA-103-D+	50	4000	11.3	0.8	22.3	41.6	1.5	1.4	5	60/97
PGA-105+	40	2600	15.1	1.9	20.5	39.3	1.5	1.5	5	63
PGA-105-D+	40	2600	15.1	1.9	18.4	36.9	1.2	1.2	5	65
PGA-106-75+	50	1500	16.9	3.3	20.1	36.2	1.4	1.5	5	116
PGA-106R-75+	5	250	17.9	3.3	19.5	34.4	1.4	1.25	5	116
PGA-106W-75+	950	2150	15.9	3.6	19.5	35.6	1.4	1.5	5	116
PGA-122-75+	5	1500	15.5	2.8	23.8	41.4	1.26	1.36	9	115
PGA-1021+	50	6000	15.1	2.3	16.8	26.5	1.35	1.11	3.3	57
PHA-1+	50	6000	13.5	2.2	22.4	42	1.7	1.3	5	146
PHA-1-D+	50	6000	13.6	2.1	22.5	39	1.6	1.3	5	155
PHA-1H+	50	6000	13.8	2.2	22.6	41	1.39	1.23	5	132
PHA-1H-D+	50	6000	13.8	2.2	22.6	41	1.39	1.23	5	132
PHA-11+	50	3000	15	2.3	21.4	41.5	2.1	2.1	5	146
PHA-13HLN+	1	1000	22.7	1.1	28.7	43	1.3	1.3	8	234
PHA-13HLN-D+	1	1000	23	1.1	19/24/18	33/40/43	1.34	1.3	3.0/5.0/8.0	71/138/234
PHA-13LN+	1	1000	22.4	1	24.5	39	1.3	1.3	5.0/3/0	138/71
PHA-22+	50	1500	16	1.9	22	41	1.5	1.5	5	146
PHA-22H+	50	3000	16	2	22.2	39	1.3	1.28	5	141
PHA-23HLN+	30	2000	21.3	1.4	28.4	44.4	1.7	1.48	8	235
PHA-23HLN-D+	30	2000	21	1.2	19/24/28	31/37/44	1.94	1.48	3.0/5.0/8.0	72/141/235
PHA-23LN+	30	2000	21	1.2	23.9	37.4	1.7	1.25	5.0/3.0	171/72
PHA-83W+	50	8000	15.7	3.3	23.3	35.5	1.57	1.28	5.0/9.0	41/110
PHA-83W-D+	50	8000	15.7	3.3	23.3	35.5	1.57	1.28	5.0/9.0	41/110
PHA-101+	50	1500	15.2	4	25.8	45	1.8	1.9	9	182
PHA-101-D+	50	1500	15.2	4	25.8	45	1.824	1.894	9	182
PHA-102+	50	6000	14.5	3.4	26.4	50	1.5	1.32	9	192
PHA-102-D+	50	6000	14.5	3.4	26.4	50	1.5	1.32	9	192
PHA-202+	30	2700	17	3.5	30.4	46.1	1.23	1.24	11	350
PHA-202-D+	30	2700	17	3.5	30.4	46.1	1.23	1.24	11	350
PMA-183PLN+	6000	18000	27.5	1.2	9.6	22.4	1.5	1.5	2.6	57
PMA-183PLN-D+	6000	18000	27.5	1.2	9.6	22.4	1.5	1.5	2.6	57
PMA-545+	50	6000	14.2	0.8	20.3	36.4	2.3	1.3	3	80
PMA-545G1-D+	400	2200	31.1	1	23.4	36.1	1.92	1.33	5	158
PMA-545G1+	400	2200	31.3	1	22.2	33.6	1.6	1.4	5	158
PMA-545G2+	1100	1600	30.4	1	22	33.6	1.6	1.4	5	158
PMA-545G3+	700	1000	31.3	0.9	21.9	33.4	1.6	1.4	5	158
PMA-5451+	50	6000	13.7	0.8	16.8	30.8	2.6	1.3	3	30
PMA-5452+	50	6000	14	0.7	18.3	34.1	2.6	1.3	3	40
PMA-5453+	50	6000	14.3	0.7	19.64	36.8	2.6	1.3	3	60
PMA-5454+	50	6000	13.5	0.9	14.6	28.1	2.9	1.3	5	20
PMA-5455+	50	6000	14	0.8	19.1	32.7	2.6	1.3	5	40
PMA-5456+	50	6000	14.4	0.8	21.5	36	2.6	1.3	5	60
PMA1-14LN+	50	10000	22.0	1.1	21.5	28.8	1.58	1.38	6	61
PMA2-33LN+	400	3000	19.1	0.38	17.2	34.5	1.9	1.2	3	56
PMA2-33LN-D+	400	3000	18.4	0.47	17.6	33.8	1.5	1.1	3	58
PMA2-43LN+	1100	4000	19.9	0.46	19.9	32.9	1.35	1.64	5	51
PMA2-43LN-D+	1100	4000	19.4	0.6	20.4	32.9	1.3	1.7	5	53
PMA2-63LN+	400	6000	19.3	0.4	16.4	30.1	1.57	1.91	5	36.4
PMA2-63LN-D+	400	6000	19.3	0.4	16.4	30.1	1.57	1.91	5	36.4
PMA2-123LN+	500	12000	16.8	2.6	14.9	27	1.96	1.17	5.0/6.0	51/68
PMA2-123LN5+	500	12000	15.1	1.2	12.2	23.4	1.9	1.3	5	30
PMA2-123LN5-D+	500	12000	15.1	1.2	12.2	23.4	1.9	1.3	5	30
PMA2-133LN+	10000	13000	15.3	1.3	13.5	28.6	1.24	1.08	3.0/5.0	13/29
PMA2-133LN-D+	10000	13000	15.3	1.3	13.5	28.6	1.24	1.08	3.0/5.0	13/29
PMA2-153LN+	500	15000	16.8	2.6	14.8	26.8	1.97	1.15	5.0/6.0	50/66
PMA2-153LN-D+	500	15000	16.8	2.6	14.8	26.8	1.97	1.15	5.0/6.0	50/66
PMA2-162LN+	700	1600	22.7	0.5	20	30	1.3	1.3	4	55
PMA2-162LN-D+	700	1600	22.7	0.5	20	30	1.3	1.3	4	55
PMA2-162LNA+	700	1600	22.7	0.5	20	30	1.3	1.3	4	55
PMA2-183LN+	4000	18000	10.4	2.5	14.2	25.6	1.79	1.43	5	48.2
PMA2-183LN-D+	4000	18000	10.4	2.5	14.2	25.6	1.79	1.43	5	48.2
PMA2-252LN+	1500	2500	17.6	0.8	17.8	30	1.3	1.3	4	57
PMA2-252LNA+	1500	2500	17.6	0.8	17.8	30	1.3	1.3	4	57
PMA3-14LN+	50	10000	22.6	1.8	22	30.4	1.49	1.28	6	67
PMA3-14LN-D+	50	10000	22.6	1.8	22	30.4	1.49	1.28	6	67
PMA3-14LV+	50	10000	21.5	1.1	20.3	27.7	1.67	1.33	5	55
PMA3-34GLN+	10000	30000	25.5	1.6	10	22	1.57	1.92	4	68
PMA3-43-1W+	10	4000	21	3.2	32.2	37	1.67	1.50	12	190
PMA3-63GLN+	1800	6000	27.9	0.7	14.1	26.6	1.78	1.92	5.0	69
PMA3-63GLN-D+	1800	6000	27.9	0.7	14.1	26.6	1.78	1.92	5.0	69
PMA3-73-1W+	300	7500	20.1	2.5	31.7	37	1.67	1.67	12	190
PMA3-83LN+	500	8000	22.1	1.3	20.7	35.2	1.38	1.58	5.0/6.0	60/77
PMA3-83LN-D+	500	8000	21.9	1.2	21.2	35	1.4	1.8	5.0/6.0	60/77
PMA3-83LNW+	400	8000	22.6	1.2	21.7	37.0	1.32	1.5	5.0/6.0	58/75
PMA3-83LNW-D+	400	8000	22.6	1.2	21.7	37.0	1.32	1.5	5.0/6.0	58/75
PMA3-83LP+	400	8000	19.5	2.8	24.6	35.4	1.61	1.71	6	150
PMA3-83MP+	400	8000	21	3.2	27.8	37.9	1.78	1.43	8	144
PMA3-83MP-D+	400	8000	21	3.2	27.8	37.9	1.78	1.43	8	144
PMA3-223GLN+	10000	22000	27.9	1.8	10	22.1	1.57	1.78	4	68
PMA3-313GLN+	26500	31000	18.2	1.6	11	23.4	2.32	2.09	4	68
PMA3-352GLN+	2500	3500	28.5	0.7	14.8	27.8	1.78	1.92	5.0	69
PMA3-453+	10000	45000	25.5	2.4	11.7	23.4	1.92	1.43	4	68
PMA3-453-D+	10000	45000	25.5	2.4	11.7	23.4	1.92	1.43	4	68
PMA3-5123+	5500	12500	21.6	1.0	16.8	28.1	1.78	1.33	4	72
PMA3-5153+	5500	15500	21.5	1.2	17	28.4	1.92	1.50	5	64
PMA3-10203+	12500	20000	22.2	1.4	16.1	25.0	2.32	1.67	5	56
PMA3-15453+	15000	45000	17	3.2	17	25	1.58	1.67	5	128
PMA3-15453-D+	15000	45000	15.6	3.6	17	24	1.54	1.65	5	128
PMA3-24323LN+	24000	32000	17	2.8	17	24	1.50	1.78	5	128
PMA4-33GLN+	700	3000	38.9	0.47	22.6	40.4	1.6	1.9	5	152
PMA4-6263LN+	6000	26500	24.6	2.5	9.9	22.8	1.78	1.5	4	52.5
PMA4-6263LN-D+	6000	26500	23.4	2.1	12	23.3	1.9	1.9	4	55
PMA5-63-2W+	10	6000	12	2.7	31.2	44.5	1.08	1.92	12	400
PMA5-83-2W+	10	10000	12.6	3.9	31	40.9	1.28	1.54	12	400
PMA5-83-2W-D+	10	10000	13.6	3.9	30.9	42.5	1.31	1.55	12	400
PMA5-83-LV+	10	10000	12.9	2.6	28.7	40.8	1.15	1.5	8	400
PMA5-123-3W+	8000	12000	28.3	7.1	34.2	42.5	1.56	1.58	7	1250
PMA5-123-3W-D+	8000	12000	29.8	7.1	34.7	39	1.54	1.53	7	1250
PSA-8A+	DC	4000	31	3	12.8	25.8	1.28	1.25	5	36
PSA-0012+	50	6000	14.2	2.4	22	35	1.7	1.4	5	74
PSA-0012-D+	50	6000	15.6	2.4	22.2	35	1.51	1.34	5	92
PSA-14+	10	10000	16.5	3.9	16.3	29.4	1.25	1.04	5	47
PSA-39+	DC	6000	23	2.2	10.7	23.3	1.28	1.22	5	32
PSA-545+	50	4000	14.9	1	20.2	36.2	2.1	1.5	3	80
PSA-5451+	50	4000	14	1	16.2	30.2	2.6	1.2	3	30
PSA-5453+	50	4000	14.7	1	19.4	36.8	2.6	1.2	3	60
PSA-5454+	50	4000	13.6	1.1	14	26.3	2.6	1.4	5	20
PSA-5455+	50	4000	14.4	1	18.5	32.2	2.3	1.3	5	40
PSA2-6+	DC	7000	16.5	2.5	3.6	16	1.36	1.53	5	15
PSA4-5043+	50	4000	18.4	0.75	18.8	33.5	1.7	1.5	3.0/5.0	33/58
PSA4-5043-D+	50	4000	18.4	0.8	19	34	1.7	1.5	5	33/58
PVGA-123+	400	12000	15.8	4.3	20.2	29.5	1.39	1.34	6	77
PVGA-123-D+	400	12000	15.6	4.5	20.2	30.0	1.59	1.49	6	77
PVGA-273+	300	26500	13.9	2.6	15.0	28.8	1.92	1.78	5/8	80
PVGA-273-D+	300	26500	15.7	2.1	17.3	28.8	1.37	1.43	5/8	80
RAM-2+	DC	2000	11.8	6.5	4.5	17	1.2	1.4	5	25
RAM-3+	DC	2000	12	6	10	23	1.6	1.7	5	35
RAM-4+	DC	1000	8	6.5	12.5	25.5	1.4	1.9	5.3	50
RAM-6A+	DC	2000	19.7	2.3	3.2	17.3	1.2	1.2	3.5	16
RAM-7+	DC	2000	12.5	4.5	5.5	19	2	1.8	4	22
RAM-8A+	DC	1000	28	2.6	12.6	24.4	1.6	1.8	3.7	36
RAMP-33LN+	50	3000	13	1.1	16.5	30	2	1.4	5	80
RFE-3G33G7100X+	3300	3700	53	-	50	-	1.5	-	28	10000
RFE-24M30M075X+	24	30	16	-	42	-	1.9	-	65	1750
RFE-24M30M1K7X+	24	30	25	-	62.2	-	1.35	-	65	33162
RFS-2G42G5050X+	2400	2500	51.5	-	47	-	1.5	-	28	4250
RFS-2G42G51K0+	2400	2500	53.5	-	59.7	-	1.5	-	208	10000
RFS-2G42G5050+	2400	2500	51.5	-	47	-	1.5	-	28	4250
RFS-G90G93750X+	902	928	59	-	58.75	-	1.2	-	50	24000
SAV-331+	10	4000	24.1	0.5	19.6	32.3	-	-	4	60
SAV-541+	45	6000	23.2	0.5	19.2	33.1	-	-	3	60
SAV-541-D+	450	6000	19.1	0.38	21	33.1	-	-	3/4	15/30/60
SAV-551+	45	6000	20.9	0.5	17.5	24.3	-	-	3	15
SAV-581+	45	6000	22.3	0.5	19	30.6	-	-	3	30
TAMP-72LN+	400	700	20	1	21.5	36	1.35	1.15	5	90
TAMP-112-2W+	650	1200	31	2.8	30	41	1.9	2.1	5	750
TAMP-242GLN+	1710	2400	30	0.85	20	36	1.25	1.4	5	120
TAMP-242LN+	1710	2400	13	0.65	17	33.5	1.6	1.2	5	46
TAMP-272LN+	2300	2700	14	0.85	19.5	30	1.3	1.45	5	70
TAMP-362GLN+	3300	3600	20	0.9	16	29	1.3	1.3	5	100
TAMP-960LN+	824	960	18	0.55	16.5	30	1.1	1.4	5	45
TAMP-1521GLN+	1380	1520	35	0.6	13.5	27.5	1.2	1.15	5	50
TAV-541+	45	6000	23.8	0.5	19.1	33.6	-	-	3	60
TAV-551+	45	6000	21.3	0.5	17.5	23.5	-	-	3	15
TAV-581+	45	6000	22.9	0.5	18.3	30.3	-	-	3	30
TAV1-331+	10	4000	24.1	0.6	20.1	31.8	-	-	4	60
TAV1-331NM+	10	4000	20.1	0.7	20.4	31.7	-	-	4	60
TAV1-541+	45	6000	23.2	0.5	19.2	33.1	-	-	3	60
TAV1-541NM+	45	6000	16.2	0.9	20.6	34	-	-	3/4	60
TAV1-551+	45	6000	21.6	0.5	16	23.9	-	-	3	15
TAV2-14LN+	50	10000	16.4	0.7	18.8	30.9	2.615	1.577	2/4	20/40
TAV2-14LN-D+	50	10000	16.4	0.7	18.8	30.9	2.615	1.577	2/4	20/40
TAV2-501+	400	3900	15.1	1.3	27.7	42.9	-	-	4.5	280
TAV2-501-D+	400	3900	15.1	1.3	27.7	42.9	-	-	4.5	280
TO-1217LN+	1200	1700	20	1.6	10	25	2.5	2.5	15	70
TO-1724LN+	1700	2400	20	1.6	10	22	2.5	2.5	15	70
TSS-13HLN+	1	1000	23	1.4	28.4	42.9	1.43	1.37	8	234
TSS-13HLN-D+	1	1000	23	1.4	28.4	42.9	1.43	1.37	8/5/3	234/142/72
TSS-13LN+	1	1000	22.8	1.1	24.5	39.2	1.28	1.32	5/3	142/72
TSS-23HLN+	30	2000	21.8	1.4	28.5	42.6	1.92	1.67	8	236
TSS-23HLN-D+	30	2000	21.8	1.4	28.5	42.6	1.92	1.67	8/5/3	236/139/74
TSS-23LN+	30	2000	21.5	1.2	24.1	36.4	1.92	1.67	5/3	139/74
TSS-23ULN+	10	2000	20	0.4	20.3	37.3	1.43	1.57	5	70.6
TSS-44+	22000	43500	17.6	3.2	6.9	12.7	1.37	1.28	4	22
TSS-44-D+	22000	43500	17.6	3.2	6.9	12.7	1.37	1.28	4	22
TSS-53LNB+	500	5000	21.7	1.4	20.6	33.9	1.46	1.33	5	82
TSS-53LNB-D+	500	6000	21.4	1.3	19.4	35	1.2	1.4	5	82
TSS-53LNB3+	500	5000	18.4	1.5	14.9	25	1.63	1.26	3	42
TSS-183A+	5000	18000	14.2	4.4	17.9	28.9	1.37	1.28	5	145
TSS-14252LN+	1427	2570	35.1	0.8	15.8	27.9	1.06	1.29	3.3	64
TSS-66921LN+	660	920	35	1.1	16.3	25.4	1.22	1.22	3.3	58
TSS2-53LNB+	500	5000	20.9	1.25	19.1	29.1	1.49	1.46	5	80
TSY-13LNB+	30	1000	14.7	1.2	17.1	26.4	1.5	1.3	2.7	7.7
TSY-83LN+	400	8000	22.3	1.5	22.9	33.6	1.35	1.22	5.0/6.0	76/104
TSY-172LNB+	30	1700	13.1	1.4	17.5	24.7	1.9	1.5	2.7	7.7
TSY-172LNB-D+	30	1700	13.1	1.4	17.5	24.7	1.9	1.5	2.7	7.7
TSY-173LN+	13500	17000	16.5	1.1	8.7	24.2	1.28	1.19	3	13.2
TSY-173LN-D+	13500	17000	16.5	1.1	8.7	24.2	1.28	1.19	3	13.2
TVA-4W-422A+	500	4200	25	10	34	44	1.6	2.5	110/220 AC	-
TVA-63-183	6000	18000	23.6	6.9	18	26	1.5	1.25	110/220 AC	-
TVA-63-183A+	6000	18000	24	6.4	17	26	1.5	1.25	110/220 AC	-
TVA-82-213A+	800	21000	25	3	24	30	1.35	1.4	110/220 AC	-
TVA-R5-13A+	0.5	1000	38	10	34	42	1.5	2.5	110/220 AC	-
VAM-3+	DC	2000	11	6	9	22	1.5	1.7	4.7	35
VAM-6+	DC	2000	15	3	2	14	1.6	1.5	3.3	16
VAM-7+	DC	2000	12	5	5.5	18	1.5	1.5	3.8	22
VNA-25+	500	2500	18.6	5.5	18.2	29	1.5	1.6	5	85
VNA-28B+	500	2500	23	2.9	11.4	22.7	1.31	1.83	2.8/5.0	32/34
WVA-40603G+	40000	60000	34	6.5	23	24	1.40	1.40	10	450
WVA-40603GX+	40000	60000	34	6.5	23	24	1.40	1.40	10	450
WVA-44603LN+	44000	60000	46	2.5	19	21	1.50	1.50	10	275
WVA-44603LNX+	44000	60000	46	2.5	19	21	1.50	1.50	10	275
WVA-50753G+	50000	75000	44	2.5	19	22	1.50	1.50	10	460
WVA-50753GX+	50000	75000	44	2.5	19	22	1.50	1.50	10	460
WVA-60903G+	60000	90000	29.5	5	17.5	21	1.50	1.50	10	380
WVA-60903GX+	60000	90000	29.5	5	17.5	21	1.50	1.50	10	380
WVA-71863HP+	71000	86000	39	-	22.5	-	2.00	1.50	10	500
WVA-71863HPX+	71000	86000	39	-	22.5	-	2.00	1.50	10	500
WVA-71863LNX+	71000	86000	39	4.5	14.5	-	1.60	1.50	10	185
WVA-751103LNX+	75000	110000	21	3.5	-3	4	2.30	2.30	10	50
YSF-122+	800	1200	20.4	3.4	20.5	36	1.8	1.4	5	118
YSF-272+	2300	2700	19	2.5	20	35	1.4	1.3	5	118
YSF-322+	900	3200	19	2.5	20	35	1.4	1.3	5	118
YSF-2151+	900	2150	20	3.1	20	35	1.9	1.2	5	118
YSIF-421+	220	380	37.2	1.6	22.2	38.3	1.78	1.08	5	189
ZEL-0812LN	800	1200	20	1.5	8	18	2.5	2.5	15	70
ZEL-1217LN+	1200	1700	20	1.5	10	25	2.5	2.5	15	70
ZEL-1724LN+	1700	2400	20	1.5	10	22	2.5	2.5	15	70
ZFL-11AD+	2	2000	8	6.5	-2	14	2.5	2	15	22
ZFL-11ADB+	2	2000	8	6.5	-2	14	2.5	2	15	22
ZFL-272VH+	30	2700	16.9	3.4	24.5	47.2	1.13	1.31	15	350
ZFL-500+	0.05	500	20	4.2	9	18	1.9	1.9	15	80
ZFL-500-BNC+	0.05	500	20	4.2	9	18	1.9	1.9	15	80
ZFL-500B+	0.05	500	20	4.2	9	18	1.9	1.9	15	80
ZFL-500HLN+	10	500	19	3.8	16	30	1.5	1.5	15	110
ZFL-500HLNB+	10	500	19	3.8	16	30	1.5	1.5	15	110
ZFL-500LN+	0.1	500	24	2.9	5	14	1.5	1.6	15	60
ZFL-500LN-BNC+	0.1	500	24	2.9	5	14	1.5	1.6	15	60
ZFL-500LNB+	0.1	500	24	2.9	5	14	1.5	1.6	15	60
ZFL-500LNB-BNC+	0.1	500	24	2.9	5	14	1.5	1.6	15	60
ZFL-1000+	0.1	1000	17	6	9	18	1.5	2	15	105
ZFL-1000H+	10	1000	28	4	20	33	1.4	1.4	15	160
ZFL-1000HB+	10	1000	28	4	20	33	1.4	1.4	15	160
ZFL-1000LN+	0.1	1000	20	2.9	3	14	1.5	2	15	60
ZFL-1000LNB+	0.1	1000	20	2.9	3	14	1.5	2	15	60
ZFL-1000VH+	10	1000	20	4.5	25	38	2	2.5	15	320
ZFL-1000VH2+	10	1000	28	5	25	38	2	2.5	15	320
ZFL-1000VH2X+	10	1000	28	5	25	38	2	2.5	15	320
ZFL-1000VHB+	10	1000	20	4.5	25	38	2	2.5	15	320
ZFL-1000VHX+	10	1000	20	4.5	25	38	2	2.5	15	320
ZFL-1200G+	10	1200	23	6.5	8	22	1.25	1.5	15	180
ZFL-1200GB+	10	1200	23	6.5	8	22	1.25	1.5	15	180
ZFL-1200GH+	10	1200	29	5.5	13	28	1.25	1.5	15	230
ZFL-1200GHB+	10	1200	29	5.5	13	28	1.25	1.5	15	230
ZFL-2000+	10	2000	20	7	16	25	2	2	15	120
ZFL-2000B+	10	2000	20	7	16	25	2	2	15	120
ZFL-2000G+	10	2000	20	7.5	7	17	1.5	1.5	15	180
ZFL-2000GH+	10	2000	27	5.5	14	25	1.4	1.5	15	230
ZFL-2000GHB+	10	2000	27	5.5	14	25	1.4	1.5	15	230
ZFL-2000X+	10	2000	20	7	16	25	2	2	15	120
ZFL-2500+	500	2500	28	8	15	27	2.5	2.5	5	220
ZFL-2500B+	500	2500	28	8	15	27	2.5	2.5	5	220
ZFL-2500VH+	10	2500	20	5.5	23	35	1.7	2	15	300
ZFL-2500VHB+	10	2500	20	5.5	23	35	1.7	2	15	300
ZFL-2500VHX+	10	2500	20	5.5	23	35	1.7	2	15	300
ZHL-1-2W+	5	500	29	7	33	44	2.1	2.1	24	900
ZHL-1-2W-N+	5	500	29	7	33	44	2.1	2.1	24	900
ZHL-1-2W-S+	5	500	29	7	33	44	2.1	2.1	24	900
ZHL-1-2WX+	5	500	29	7	33	44	2.1	2.1	24	900
ZHL-1-2WX-S+	5	500	29	7	33	44	2.1	2.1	24	900
ZHL-1A+	2	500	16	11	28	38	2	2	24	600
ZHL-1A-S+	2	500	16	11	28	38	2	2	24	600
ZHL-1W-63-S+	600	6000	35	12	30	35	2.5	3.5	15	1000
ZHL-1W-63X-S+	600	6000	35	12	30	35	2.5	3.5	15	1000
ZHL-2-8-S+	10	1000	34	7	29	42	2	2	24	700
ZHL-2-8X-S+	10	1000	34	7	29	42	2	2	24	700
ZHL-2-12+	10	1200	26	5	29	45	2.2	2.2	24	750
ZHL-2-12X+	10	1200	26	5	29	45	2.2	2.2	24	750
ZHL-2-S+	10	1000	20	9	29	42	2	2.1	24	600
ZHL-2W-63-S+	600	6000	42	12	33	38	2.5	3.5	28	2000
ZHL-2W-63X-S+	600	6000	42	12	33	38	2.5	3.5	28	2000
ZHL-2X-S+	10	1000	20	9	29	42	2	2.1	24	600
ZHL-03-5WF+	60	300	35	3	36	49	1.4	1.5	24	2800
ZHL-3A+	0.4	150	24	11	29.5	38	2	2	24	600
ZHL-03-5WFX+	60	300	35	3	36	49	1.4	1.5	24	2800
ZHL-3A-S+	0.4	150	24	11	29.5	38	2	2	24	600
ZHL-4W-422+	500	4200	25	10	34	44	1.6	2.6	28	3000
ZHL-4W-422X+	500	4200	25	10	34	44	1.6	2.6	28	3000
ZHL-5W-1+	5	500	45	4	37	49	2	2.5	24	3300
ZHL-5W-1X+	5	500	45	4	37	49	2	2.5	24	3300
ZHL-5W-2G+	800	2000	45	8	37	44	1.7	1.5	24	2000
ZHL-5W-2GX+	800	2000	45	8	37	44	1.7	1.5	24	2000
ZHL-5W-63-S+	600	6000	45	12	37	42	2.5	3.5	28	3500
ZHL-5W-63X-S+	600	6000	45	12	37	42	2.5	3.5	28	3500
ZHL-5W-202-S+	10	2000	50	10	36	45	1.2	2.0	28	3000
ZHL-5W-422+	500	4200	25	7	35	45	1.7	5.47	28	3000
ZHL-5W-422X+	500	4200	25	7	35	45	1.7	5.47	28	3000
ZHL-6A+	0.0025	500	25	9.5	22	34	1.8	2	24	350
ZHL-6A-S+	0.0025	500	25	9.5	22	34	1.8	2	24	350
ZHL-10M4G21W0+	10	4200	37	6	32	44	1.3	1.5	28	800
ZHL-10M4G21W0X+	10	4200	37	6	32	44	1.3	1.5	28	800
ZHL-10M4G21W1+	10	4200	44	5.6	33	46	1.3	1.5	28	860
ZHL-10M4G21W1X+	10	4200	44	5.6	33	46	1.3	1.5	28	860
ZHL-10M4G21W2+	10	4200	44	5.6	33	46	1.3	1.5	110/220 AC	-
ZHL-10W-2G+	800	2000	43	7	40	50	1.3	1.3	24	5000
ZHL-10W-2GX+	800	2000	43	7	40	50	1.3	1.3	24	5000
ZHL-10W-202-S+	10	2000	50	10	38	45	2.0	2.0	28	5000
ZHL-15W-422-S+	600	4200	46	10	39	47	1.7	3.5	28	3500
ZHL-15W-422X-S+	600	4200	46	10	39	47	1.7	3.5	28	3500
ZHL-16W-43+	1800	4000	45	6	41	47	1.5	1.3	28	4300
ZHL-20W-13+	20	1000	50	3.5	41	50	1.7	2.5	24	2800
ZHL-20W-13SW+	20	1000	50	3.5	41	50	1.7	2.5	24	2800
ZHL-20W-13SWX+	20	1000	50	3.5	41	50	1.7	2.5	24	2800
ZHL-20W-13X+	20	1000	50	3.5	41	50	1.7	2.5	24	2800
ZHL-20W-83-S+	4000	8000	56	11	39	50	1.6	1.7	28	4000
ZHL-20W-83X-S+	4000	8000	56	11	39	50	1.6	1.7	28	4000
ZHL-20W-202-S+	20	2000	53	10	39	45	2.0	3.5	28	4000
ZHL-20W-202X-S+	20	2000	53	10	39	45	2.0	3.5	28	4000
ZHL-25W-63+	700	6000	53	13	37	45	1.8	2	24	12000
ZHL-25W-63X+	700	6000	53	13	37	45	1.8	2	24	12000
ZHL-25W-272+	20	2700	50	10	40	49	2	3.5	28	3700
ZHL-25W-272X+	20	2700	50	10	40	49	2	3.5	28	3700
ZHL-30W-252+	600	2500	50	5.5	44	52	1.3	1.2	28	6300
ZHL-30W-252X-S+	600	2500	50	5.5	44	52	1.3	1.2	28	6300
ZHL-30W-262+	2300	2550	50	7	43	50	1.3	1.3	28	4300
ZHL-30W-262X-S+	2300	2550	50	7	43	50	1.3	1.3	28	4300
ZHL-32A+	0.05	130	25	10	29	38	2	2	24	600
ZHL-32A-S+	0.05	130	25	10	29	38	2	2	24	600
ZHL-40W-372-S+	3400	3700	50	15	46	52	1.5	1.5	28	6200
ZHL-42+	600	4200	34	8	30	38	2.5	2.5	15	1000
ZHL-42W+	10	4200	30	8	28	38	2.5	2.5	15	880
ZHL-42WX+	10	4200	30	8	28	38	2.5	2.5	15	880
ZHL-42X+	600	4200	34	8	30	38	2.5	2.5	15	1000
ZHL-50W-52+	50	500	50	6	47.5	55	1.6	2	24	9300
ZHL-50W-63+	700	6000	59	11	42	53	1.5	1.5	40	6000
ZHL-50W-GAN+	20	500	43.5	7	48	55	1.7	2.6	28	7400
ZHL-50W-GANX+	20	500	43.5	7	48	55	1.7	2.6	28	7100
ZHL-72A+	0.0025	700	25	7.7	24	34	2	2	24	350
ZHL-100W-13+	800	1000	50	7	49	60	1.3	1.4	28	14500
ZHL-100W-52+	50	500	50	6.5	48.5	57	1.45	2.5	24	10500
ZHL-100W-63+	2500	6000	58	12	43	54	2	1.2	30	8000
ZHL-100W-272+	700	2700	48	8.2	49	50	1.5	1.5	30	16000
ZHL-100W-352+	3000	3500	50	7.3	50	55	1.35	1.5	28	20000
ZHL-100W-382+	3250	3850	50	9.5	50	58	1.3	1.3	28	18000
ZHL-100W-GAN+	20	500	42	7	49	60	1.5	2.5	30	9400
ZHL-100W-GANX+	20	500	42	7	49	60	1.5	2.5	30	9400
ZHL-122LM+	40	1200	12.3	3.9	23	40	1.5	1.5	6	260
ZHL-0812HLN+	800	1200	36	1.5	26	36	1.4	1.3	15	725
ZHL-0812HLNX+	800	1200	36	1.5	26	36	1.4	1.3	15	725
ZHL-1000-3W+	500	1000	44	3.5	37	45	2	2.5	24	2250
ZHL-1000-3WX+	500	1000	44	3.5	37	45	2	2.5	24	2250
ZHL-1010+	50	1000	9.5	3.5	26	46	2	2	12	525
ZHL-1042J+	10	4200	25	6	20	30	2.5	2.5	15	330
ZHL-1042JX+	10	4200	25	6	20	30	2.5	2.5	15	330
ZHL-1217HLN+	1200	1700	36	1.5	26	36	1.4	1.3	15	725
ZHL-1217HLNX+	1200	1700	36	1.5	26	36	1.4	1.3	15	725
ZHL-1217MLN+	1200	1700	35	1.1	22	36	1.4	1.3	15	380
ZHL-1724HLN+	1700	2400	30	1.5	26	36	1.4	1.6	15	725
ZHL-1724HLNX+	1700	2400	30	1.5	26	36	1.4	1.6	15	725
ZHL-2010+	50	1000	20	3.7	26	46	2	2	12	900
ZHL-2150+	950	2450	30	3.5	11	25	1.3	1.3	12	110
ZHL-2425-250+	2400	2500	42	-	54.5	-	1.9	-	32	15000
ZHL-2425-250X+	2400	2500	42	-	54.5	-	1.9	-	32	15000
ZHL-3010+	50	1000	30	5.5	26	46	2	1.6	12	1000
ZHL-4240+	600	4200	42	8	30	38	2.5	2.5	15	1000
ZHL-4240X+	600	4200	42	8	30	38	2.5	2.5	15	1000
ZHL0G60G7100+	600	700	50	7	48.5	-	1.6	-	28	14000
ZHL0G60G7100X+	600	700	50	7	48.5	-	1.6	-	28	14000
ZHL2G02G4125+	2000	2400	52	7	49.5	-	2	-	28	17000
ZHL6G018G020+	6000	18000	57	6.8	34	42	1.4	2	20	5000
ZHL6G018G020X+	6000	18000	57	6.8	34	42	1.4	2	20	5000
ZJL-3G+	20	3000	14	3.8	8	22	1.4	1.6	12	45
ZJL-4G+	20	4000	12.4	5.5	14	30.5	1.4	1.6	12	75
ZJL-4HG+	20	4000	17	4.5	15	30	1.5	1.4	12	75
ZJL-5G+	20	5000	9	8.5	15	32	1.6	1.3	12	80
ZJL-6G+	20	6000	13	4.5	10	24	1.5	1.4	12	50
ZJL-7G+	20	7000	10	5	9	24	1.5	1.5	12	50
ZJL-153+	5000	15000	13	6	18	23	1.7	1.7	5	180
ZKL-1R5+	10	1500	40	3	15	31	1.4	1.6	12	115
ZKL-2+	10	2000	33.5	4	15	31	1.4	1.4	12	120
ZKL-2R5+	10	2500	30	5	15	31	1.4	1.4	12	120
ZKL-2R7+	10	2700	24	5	13	30	1.3	1.4	12	120
ZKL-33ULN-S+	400	3000	35	0.36	18	37	1.3	1.4	5	100
ZPUL-30P+	0.0025	700	35	7.7	22	34	2	2	24	400
ZQL-900LN+	824	849	15	1.3	21	35	1.2	1.1	15	160
ZQL-900MLN+	824	849	25.5	1.5	24.5	41	1.3	1.4	15	230
ZQL-1900LN+	1850	1910	15	1.5	19	37	1.15	1.25	15	160
ZQL-2700MLNW+	2200	2700	25	1.5	25	38	1.25	1.15	15	350
ZRL-400+	150	400	31	2.5	25	42	1.5	1.25	12	450
ZRL-700+	250	700	30	2	23.5	46	1.1	1.1	12	575
ZRL-1150LN+	650	1400	33	1	25	41	1.4	1.3	12	500
ZRL-1200+	650	1200	28	2	23.5	46	1.2	1.2	12	575
ZRL-2150+	950	2150	25	1.5	22	34	1.3	1.2	12	300
ZRL-2300+	1400	2300	29	2.5	26	42	1.2	1.16	12	470
ZRL-2400LN+	1000	2400	30	1	23	39	1.6	1.4	12	520
ZRL-3500+	700	3500	21	2.4	24	45	1.4	1.3	12	460
ZRON-8G+	2000	8000	20	6	20	30	2	2	15	310
ZRON-8GX+	2000	8000	20	6	20	30	2	2	15	310
ZVA-0.5W303G+	10	30000	24.5	4.5	25	35	1.6	1.8	12	460
ZVA-0.5W303GX+	10	30000	24.5	4.5	25	35	1.6	1.8	12	460
ZVA-1W-103+	500	10000	39	4	30	39	1.5	1.4	15	750
ZVA-1W-103X+	500	10000	39	4	30	39	1.5	1.4	15	750
ZVA-183-S+	700	18000	26	3	24	33	1.35	1.25	12	400
ZVA-183A-S+	700	18000	24.5	4.5	24	34	1.35	1.35	12	400
ZVA-183G-S+	500	18000	38	3	25	36	1.9	2	15	770
ZVA-183W-S+	100	18000	28	3	26	34.5	1.3	1.6	15	625
ZVA-183X-S+	700	18000	26	3	24	33	1.35	1.25	12	400
ZVA-183AX-S+	700	18000	24.5	4.5	24	34	1.35	1.35	12	400
ZVA-183GX-S+	500	18000	38	3	25	36	1.9	2	15	770
ZVA-183WA-S+	100	18000	25	4	29	38	1.3	1.5	12	500
ZVA-183WX-S+	100	18000	28	3	26	34.5	1.3	1.6	15	625
ZVA-183WAX-S+	100	18000	25	4	29	38	1.3	1.5	12	500
ZVA-203GX+	1500	21000	29	3	15.5	27.5	1.5	1.6	5	450
ZVA-213-S+	800	21000	26	3	24	33	1.35	1.25	12	400
ZVA-213A-S+	800	21000	24.5	4.5	24	34	1.35	1.35	12	400
ZVA-213X-S+	800	21000	26	3	24	33	1.35	1.25	12	400
ZVA-213AX-S+	800	21000	24.5	4.5	24	34	1.35	1.35	12	400
ZVA-213UWX+	100	20000	14	3	16	29	1.3	1.4	+12, -5	84
ZVA-403GX+	0.05	40000	11	4.5	11	21	1.45	1.6	5	100
ZVA-443HGX+	10	43500	33	5	9	18	1.5	1.8	15	170
ZVA-443X+	0.05	43500	11	4.5	10	22	1.8	1.9	5	80
ZVA-503GX+	0.05	50000	11	5	11	21	1.50	1.60	5	100
ZVA-543+	18000	54000	34	6	26	34	1.30	1.40	10	850
ZVA-543HP+	18000	54000	31	6.5	28	37	1.50	1.50	10	1650
ZVA-543HPX+	18000	54000	31	6.5	28	37	1.50	1.50	10	1500
ZVA-543LN+	20000	54000	40	3.5	29	36	1.4	1.4	10	1650
ZVA-543LNX+	20000	54000	40	3.5	29	36	1.4	1.4	10	1500
ZVA-543X+	18000	54000	34	6	26	34	1.30	1.40	10	800
ZVA-01243+	1000	22000	12.8	5	21.6	27.5	1.7	1.4	8	170
ZVA-02203LN+	2000	20000	30	3	20	28	1.56	1.56	12	290
ZVA-02203LNX+	2000	20000	30	3	20	28	1.56	1.56	12	290
ZVA-02303HP+	500	30000	38	3.8	27	35	1.3	1.2	15	400
ZVA-02303HPX+	500	30000	38	3.8	27	35	1.3	1.2	15	400
ZVA-02443HP+	2000	43500	37	5	17	25	1.5	2.5	15	280
ZVA-02443HPX+	2000	43500	37	5	17	25	1.5	2.5	15	280
ZVA-02653G+	2000	65000	21	5	16	23	1.5	1.5	10	270
ZVA-02653GX+	2000	65000	21	5	16	23	1.5	1.5	10	270
ZVA-5803X+	500	80000	17	5	10	23	1.5	1.5	10	130
ZVA-18403G+	18000	40000	43	3.8	22	28	1.8	2.5	15	190
ZVA-18403GX+	18000	40000	43	3.8	22	28	1.8	2.5	15	190
ZVA-18443TC+	18000	43500	45	5.5	29	41	1.5	1.5	15	1400
ZVA-18443TCX+	18000	43500	45	5.5	29	41	1.5	1.5	15	1300
ZVA-18443VG+	18000	43500	47	5	30	41	1.5	1.5	10	1400
ZVA-18443VGX+	18000	43500	47	5	30	41	1.5	1.5	10	1300
ZVA-20543TC+	20000	54000	48	4.5	29	37	1.5	1.5	15	1800
ZVA-20543TCX+	20000	54000	48	4.5	29	37	1.5	1.5	15	1700
ZVA-20543VG+	20000	54000	50	4	30	37	1.5	1.5	10	1800
ZVA-20543VGX+	20000	54000	50	4	30	37	1.5	1.5	10	1700
ZVA-24443G1+	24000	43500	45	1.7	20	27	2	2.5	15	160
ZVA-24443G1X+	24000	43500	45	1.7	20	27	2	2.5	15	160
ZVA-24443HP+	24000	43500	47	2.2	25	40	1.8	1.8	15	1400
ZVA-24443HPX+	24000	43500	47	2.2	25	40	1.8	1.8	15	1300
ZVA-35703+	35000	71000	17.5	-	19.5	28	1.50	1.50	15	210
ZVA-35703X+	35000	71000	17.5	-	19.5	28	1.50	1.50	15	210
ZVA-40703G+	40000	70000	34	6.5	22	30	1.50	1.50	10	470
ZVA-40703GX+	40000	70000	34	6.5	22	30	1.50	1.50	10	470
ZVA-44703LN+	44000	70000	45	2.7	18	28	1.6	1.6	10	300
ZVA-44703LNX+	44000	70000	45	2.7	18	28	1.6	1.6	10	300
ZVA-50953G+	50000	95000	28	-	17	-	1.67	1.67	10	370
ZVA-50953GX+	50000	95000	28	-	17	-	1.67	1.67	10	370
ZVA-50953X+	45000	95000	17	-	14	-	1.7	1.7	10	140
ZVA-71863HP+	71000	86000	37	-	22	-	1.60	1.60	10	490
ZVA-71863HPX+	71000	86000	37	-	22	-	1.60	1.60	10	490
ZVA-71863LNX+	71000	86000	37	4.5	13	-	1.60	1.60	10	180
ZVE-2W-272+	700	2700	33	9.5	32	39.5	1.9	1.5	15	800
ZVE-2W-272X+	700	2700	33	9.5	32	39.5	1.9	1.5	15	800
ZVE-3W-83+	2000	8000	35	5.8	33	42	1.5	1.4	15	1500
ZVE-3W-83X+	2000	8000	35	5.8	33	42	1.5	1.4	15	1500
ZVE-3W-183+	5900	18000	35	5.5	34	44	1.5	1.2	15	2200
ZVE-6W-83+	2000	8000	33	10	37	40	1.9	1.4	15	5000
ZVE-6W-83X+	2000	8000	33	10	37	40	1.9	1.4	15	5000
ZVE-8G+	2000	8000	30	4	30	40	2	2	12	1200
ZVE-8GX+	2000	8000	30	4	30	40	2	2	12	1200
ZVE-143-S+	8000	14000	19	4.5	28	35	1.5	1.5	12	450
ZVE-143X-S+	8000	14000	19	4.5	28	35	1.5	1.5	12	450
ZVE-0234LNX-K+	2000	30000	16.5	2.5	13.5	25	1.5	1.5	6	58
ZVE-323LN-K+	18000	32000	20	3	10	23	1.9	1.8	12	50
ZVE-323LNX-K+	18000	32000	20	3	10	23	1.9	1.8	12	50
ZVE-373LN-K+	28000	37000	20	2.5	9	20	1.5	1.4	12	75
ZVE-373LNX-K+	28000	37000	20	2.5	9	20	1.5	1.4	12	75
ZVE-403-K+	26000	40000	22	9	19	21	2	2	12	300
ZVE-433+	18000	43500	33	6	28	37	1.5	1.5	15	750
ZVE-433G+	18000	43500	41	7	27	39	1.5	1.5	15	730
ZVE-433GX+	18000	43500	41	7	27	39	1.5	1.5	15	530
ZVE-433HP+	18000	43500	39	6	30	40	1.5	1.5	15	1100
ZVE-433HPX+	18000	43500	39	6	30	40	1.5	1.5	15	900
ZVE-433X+	18000	43500	33	6	28	37	1.5	1.5	15	550
ZVE-453+	18000	45000	33	-	28	37	1.50	1.50	15	750
ZVE-453G+	18000	45000	41	-	27	39	1.50	1.50	15	730
ZVE-453GX+	18000	45000	41	-	27	39	1.50	1.50	15	730
ZVE-453HP+	18000	45000	39	-	30	40	1.50	1.50	15	1100
ZVE-453HPX+	18000	45000	39	-	30	40	1.50	1.50	15	1100
ZVE-453X+	18000	45000	33	-	28	37	1.50	1.50	15	750
ZVM-273HP+	13000	26500	14.5	9	25	34	1.1	1.5	12	559
ZVM-273HPX+	13000	26500	14.5	9	25	34	1.1	1.5	12	559
ZX60-14LN-S+	50	10000	22	1.5	21	32	1.4	1.3	6	72
ZX60-24-S+	5000	20000	24	6.8	18	27	1.4	1.4	5	260
ZX60-24A-S+	5000	20000	24	6.4	18.3	25.4	1.2	1.6	5	270
ZX60-33LNR-S+	50	3000	14.1	1.1	19	35	2	1.6	5	80
ZX60-43-S+	0.5	4000	17	5.4	17.3	33	1.2	2	5	110
ZX60-43LPN+	0.5	4000	20	5.8	21	34	1.3	2	6	120
ZX60-53LN+	500	5000	21	1.45	19	32	1.6	1.3	5	80
ZX60-53LNB-S+	500	5000	20	1.45	19.5	32	1.6	1.2	5	105
ZX60-63GLN+	1800	6000	27.8	1.2	13.6	26	1.7	1.7	5	67
ZX60-83LN-S+	500	8000	22.1	1.4	20.7	35.2	1.38	1.58	5.0/6.0	60/70
ZX60-83LN12+	500	8000	22.1	1.4	20.7	35.2	1.38	1.58	12	77
ZX60-83MP-S+	400	8000	20	3.2	27	40	1.6	1.5	8	144
ZX60-100VH+	0.3	100	36	4	30	43	1.6	1.5	12	370
ZX60-100VHX+	0.3	100	36	4	30	43	1.6	1.5	12	370
ZX60-112LN+	400	1100	27	1.2	16.5	30	1.4	1.3	5	190
ZX60-123LN-S+	500	12000	17	2.4	16	28	1.45	1.3	12	82
ZX60-123LPN+	50	10000	16	4.3	13.5	23	1.5	1.8	5	48
ZX60-153LN-S+	500	15000	16	2.8	15	27	2	1.5	12	82
ZX60-183-S+	6000	18000	23.5	6.9	18.1	27.2	1.4	1.4	5	260
ZX60-183A-S+	6000	18000	28	5	18	27	1.4	1.4	5	260
ZX60-223LPN+	10	22000	16	5.5	17	27	1.6	1.8	6	110
ZX60-242GLN-S+	1710	2400	30	0.85	20	37	1.4	1.6	5	150
ZX60-242LN-S+	1710	2400	13	0.75	16.5	33	1.2	1.6	5	46
ZX60-272LN-S+	2300	2700	14	0.8	18.5	31.5	1.2	1.6	5	70
ZX60-362GLN-S+	3300	3600	20	0.9	16	29	1.2	1.4	5	140
ZX60-362LN-S+	3300	3600	11.5	0.9	10.5	22	1.4	1.4	5	30
ZX60-542LN-S+	4400	5400	24	1.9	10	23	1.5	1.5	12	80
ZX60-0916LN-S+	824	960	18	0.55	16.5	30	1.2	1.4	5	45
ZX60-1215LN-S+	800	1400	16	0.4	12.5	27	1.7	1.4	12	50
ZX60-1614LN-S	1217	1620	14	0.5	13.5	30	1.3	1.3	12	50
ZX60-02203+	2000	20000	21.5	6.5	14.6	28	1.75	1.55	5	155
ZX60-02203LPN+	2000	20000	16	5	17	31	1.92	1.67	5	79
ZX60-2411BM-S+	800	2400	11.5	3.5	24	46.5	1.2	1.2	5	280
ZX60-2510MA-S+	500	2500	15	5.4	20	32	1.4	1.4	2.8/5.0	104
ZX60-2514MA-S+	500	2500	17.8	4.5	19	31	1.4	1.5	2.8/5.0	94
ZX60-2522MA-S+	500	2500	24	2.6	20.5	32	1.4	1.4	2.8/5.0	110
ZX60-2531MA-S+	500	2500	40	3.1	19	26	1.3	1.7	2.8/5.0	130
ZX60-2534MA-S+	500	2500	43	2.6	19	18	1.6	1.6	2.8/5.0	190
ZX60-3011+	400	3000	11	1.7	21.1	31	1.7	1.6	12	120
ZX60-3018G-S+	20	3000	20	2.7	11.8	25	1.3	1.4	12	34
ZX60-3800LN-S+	3300	3800	23	0.9	18	36	1.2	1.4	5	110
ZX60-4016E-S+	20	4000	18	3.9	16.5	30	1.3	1.3	12	65
ZX60-04183LN+	4000	18000	12	2.5	15	26	1.8	1.5	5	46
ZX60-05113LN+	5000	11000	21.4	1.9	13	24.5	1.9	1.5	5	42
ZX60-5916MA-S+	1500	6000	18	6.6	16.5	27	1.6	1.7	2.8/5.0	103
ZX60-6013E-S+	20	6000	14	3.3	10.3	28.7	1.5	1.2	12	39
ZX60-06183LN+	6000	18000	19	2.6	15	26.5	1.9	1.65	5	110
ZX60-06183P+	6000	18000	24	1.6	8	18	1.9	1.5	5	56
ZX60-06203ALN+	6000	20000	19	2.6	15	26.5	1.9	1.65	5	110
ZX60-8008E-S+	20	8000	9	4.1	9.3	24	1.4	1.7	12	39
ZX60-10223G+	10000	20000	26	2.3	10	20	2	1.9	5	75
ZX60-14012L-S+	0.3	14000	12	5.5	11	20	1.3	1.7	12	62
ZX60-16213+	16000	21000	20	4.5	23	33	1.7	1.6	6	260
ZX60-H242+	700	2400	14.5	3	23	46	1.4	1.5	5.5	145
ZX60-P33ULN+	400	3000	14.8	0.4	17.4	35	1.9	1.3	3	67
ZX60-P103LN+	50	3000	13	0.6	22.5	40	1.6	1.6	5	120
ZX60-P105LN+	40	2600	15	2	20	35	1.5	1.5	5	77
ZX60-P162LN+	700	1600	22.5	0.5	19.9	29.9	1.2	1.4	4	60
ZX60-R5183P+	500	18000	8.2	4.5	10.8	19	1.9	2.1	5	48
ZX60-V62+	50	6000	15.4	5.1	19	33.4	1.3	1.8	5	82
ZX60-V63+	50	6000	20.3	3.7	17.8	31.2	1.5	1.5	5	69
ZX60-V81-S+	20	6000	9.7	8	18.5	36	1.2	1.25	5	103
ZX60-V82-S+	20	6000	13.5	6.8	20	35.8	1.3	1.5	5	100
ZX60-V83-S+	20	4700	16.8	6	17	31	1.25	1.7	5	72
